GREEN MAX ECO RECESS

GREEN MAX ECO RECESS

MỤC ĐÍCH SỬ DỤNG

The Green Max Eco Recess downlight series can show high brightness, without seeing the lamp itself. Suitable for application such as household, exhibition hall, hotel, shops, jewellery store, hospital and meeting rooms.



CẤU TẠO

Using high lumen SMD light source high intensity aluminium shell, heat faste. Using good reflectivity light leading board, it is thinner and brighter, the light is more equally. Low voltage and constant current driver, no glare, the light is soft. Launch in 0.01sec. Energy saving, belongs to grand environmental light.

DIMENSION OF FITTING

ROUND

Product
Code
Wattage Lumens Color Temperature H
mm
Diameter
mm
Cut out
Diameter
GMECO-RR-05 5W 450lm 3000K,4000K,6000K 25 86 75
GMECO-RR-09 9W 810lm 3000K,4000K,6000K 25 120 105
GMECO-RR-12 12W 1080lm 3000K,4000K,6000K 25 150 135
GMECO-RR-18 18W 1620lm 3000K,4000K,6000K 25 170 135
GMECO-RR-24 24W 2160lm 3000K,4000K,6000K 25 223 205

SQUARE

Product
Code
Wattage Lumens Color Tempersture H
mm
WxL
mm
Cut out
WxL
GMECO-RS-05 5W 450lm 3000K,4000K,6000K 25 86 75
GMECO-RS-09 9W 810lm 3000K,4000K,6000K 25 120 105
GMECO-RS-12 12W 1080lm 3000K,4000K,6000K 25 150 135
GMECO-RS-18 18W 1620lm 3000K,4000K,6000K 25 170 155
GMECO-RS-24 24W 2160lm 3000K,4000K,6000K 25 223 205
